2PC Stainless Steel Ball Valve, Full Port, Thread Ends
Datasheet
Download datasheet (PDF)Specifications are indicative. Final specification is confirmed at quotation.
Specifications
Confirmed at quote- Size Range
- NPS 1/4" to NPS 4"
- Pressure Class
- 1000 WOG (69 bar / 1000 psi)
- End connection
- Threaded
- Operating temperature
- -20°C to 300°C, by material
Standards
- Inspection & test
- API 598
- Face to face
- DIN 3202, ISO 5752
- Flange & end dimension
- DIN 259/2999, ISO 228
- Mounting
- ISO 5211
- Materials
- ASTM A351, ASTM A216
- Other standards
- ANSI B1.20.1, BS 21/2779, BS 21, BS 2779, DIN 2999
Configure your variant(manually adjust box on the right if you require a different spec)
- Size
- Pressure
- End connection
Materials
All available material options per part. Click a pill to set it in the configurator.
- Body
- Seat
Temperature by material
The temperature limit follows the material grade, so the range above spans every grade offered rather than any one build. Confirmed at quotation.
- RPTFEseat
- -20°C to 180°C
- PPLseat
- -20°C to 300°C
Operating media
Typical applications
- HVAC
- Water Supply & Sewage
- Food & Beverage
- Chemical/Petrochemical/Processing
- Power & Utilities
- Paper and Pulp
- Ship Building
- Municipal water systems
- Engineering projects
Actuation options
Approvals
Features
- Two-piece body design
- Full bore
- Quarter-turn operation
- Threaded end connections
- Full bore flanged ball valve
- Two-piece body construction
- Dimensions indicated: L (face-to-face), H (overall height), D (flange outer diameter), D1 (bolt circle diameter), DN (nominal bore), n-d (number and diameter of flange bolt holes)
Description
Two-piece body stainless steel ball valve with full bore and threaded end connections, for use in water, oil, gas, acid, steam, and industrial pipeline systems. Available in sizes 1/4 in to 4 in with quarter-turn operation. Body materials include ASTM A351 CF8M, CF8, CF3M, SS316, SS304, and ASTM A216 WCB. Seat options are RPTFE and PPL.
Selection notes
This ball valve is a 2-piece, full port and threaded end pattern, supplied for threaded installation.
Sizes run NPS 1/4" to NPS 4", in 1000 WOG (69 bar / 1000 psi).
The body is offered in ASTM A351 CF8M, ASTM A351 CF8, ASTM A351 CF3M and SS316, so the grade can be matched to the service rather than the other way round.
Seat and trim options are RPTFE and PPL. The seat, not the body, usually sets the temperature and medium limit, so confirm it against the service before ordering.
Stated service media include water, oil, gas and steam.
It is catalogued for Water & Wastewater, HVAC and Industrial Process.
Working temperature is -20°C to 300°C, by material.
Built to DIN 3202, ISO 5752, API 598, ASTM A351 and ASTM A216.
