FBLC - Concentric Flange Butterfly Valve
Datasheet
Download datasheet (PDF)Specifications are indicative. Final specification is confirmed at quotation.
Specifications
Confirmed at quote- Size Range
- DN50 to DN1200
- Pressure Class
- PN10, PN16
- End connection
- Flanged
- Operating temperature
- -10°C to 120°C
Standards
- Design & manufacture
- EN 593, EN ISO 5752, EN 1074-2, ISO 5752, DIN 3202, BS 5155, ISO 5211
Configure your variant(manually adjust box on the right if you require a different spec)
- Size
- Pressure
- End connection
Materials
All available material options per part. Click a pill to set it in the configurator.
- Body
- Disc
- Seat
- Stem
Pressure-temperature rating
Maximum working pressure at each temperature, per pressure class.
| Class | Temperature | Max pressure |
|---|---|---|
| — | -10°C | 10 bar |
| — | 120°C | 10 bar |
| — | -10°C | 16 bar |
| — | 120°C | 16 bar |
Dimensions per size(6 sizes)
| Size | OD (mm) | OD1 (mm) | n-Od (mm) | H1 (mm) | H2 (mm) | L (mm) | L1 (mm) | Weight |
|---|---|---|---|---|---|---|---|---|
| DN50 | 125 | 165 | 4-Ø19 | 183 | 82.5 | 110 | 176 | — |
| DN65 | 145 | 185 | 4-Ø19 | 196 | 93 | 114 | 176 | — |
| DN80 | 160 | 200 | 8-Ø19 | 208 | 100 | 116 | 176 | — |
| DN100 | 180 | 220 | 8-Ø19 | 232 | 110 | 129 | 215 | — |
| DN125 | 210 | 250 | 8-Ø19 | 252 | 125 | 142 | 260 | — |
| DN150 | 240 | 285 | 8-Ø23 | 272 | 143 | 142 | 260 | — |
Typical applications
- Water distribution
- Raw water
- Treated effluent
- Irrigation
- Water treatment plants
Actuation options
Coatings
Approvals
Features
- The FBLC is a resilient-seated concentric butterfly valve with a pinless disc design that eliminates the corrosion and leakage path associated with conventional pin/stem connections
- The EPDM seat is moulded integrally into the body, providing a positive bubble-tight seal
- Fusion-bonded epoxy coating provides corrosion protection for buried or wet-well service
- Available with handwheel, gearbox or electric actuator
Description
The FBLC is a resilient-seated concentric butterfly valve with a pinless disc design that eliminates the corrosion and leakage path associated with conventional pin/stem connections. The EPDM seat is moulded integrally into the body, providing a positive bubble-tight seal. Fusion-bonded epoxy coating provides corrosion protection for buried or wet-well service. Available with handwheel, gearbox or electric actuator.
Selection notes
This butterfly valve is supplied for flanged installation.
Sizes run DN50 to DN1200, in PN10, PN16.
The body is Ductile Iron.
Seat and trim options are EPDM. The seat, not the body, usually sets the temperature and medium limit, so confirm it against the service before ordering.
It is catalogued for Water & Wastewater and HVAC.
Working temperature is -10°C to 120°C, and the pressure rating falls as temperature rises: read the pressure-temperature table below rather than the headline class.
Built to EN 593, EN ISO 5752, EN 1074-2, ISO 5752 and DIN 3202.
